This host is a real looker! For a single LED build, just add a 16mm MCPCB and 17mm driver.
To build a triple LED flashlight, you will need to add the following components:
- 17mm Driver
- If you are running more than a 3.4A driver, you must bypass the tailcap switch spring using either copper braid or thin 22AWG / 24AWG silicone wire.
- (3) LEDs on a 20mm 3XP MCPCB
- Aluminum or Copper Spacer
- You will have to drill and chamfer a small hole in the brass pill to allow the wires to pass through.
- Aluminum is less expensive and lighter weight, while copper offers a small thermal advantage.
- Carclo 105xx Optic
- Thermal Compound
This host works with protected cells, including the Protected NCR18650B and Protected NCR18650GA.
Specifications:
- Reflector Finish: Orange Peel
- Reverse-clicky Switch
- Uses 1x 18650 battery
- Driver Diameter: 17mm
- MCPCB Diameter: 16mm
- Includes Lanyard
- Diameter: 24mm
- Length: 119mm
- Weight: 88g
Convoy S2+ Flashlight Host - Red
- Brand: Convoy
- Product Code: CON-S2+-RED-HOST
- Availability: 14
-
$14.45
